Acorn Electron SD Interface Mk2

Features

• Uses normal FAT32 formatted Micro SD cards up to 8GB
• Connects directly to the Electron's expansion port
• Needs no additional hardware (except the Electron of course!)
• Compatible with most disk-based Electron games

About this device

The Mk2 is similar to the Mk1, but with the MicroSD reader mounted directly on the PCB rather than on a cable. People complained about the cable. They complained quite a bit, so I gave in and modified the design. I also switched from using an EPROM to a Flash chip. EPROMS have been obsolete for years and sales of the Mk1 board were good enough that sourcing chips was starting to become a significant headache.

The Mk2 sold exteremly well, to the point were I couldn't keep up with demand as it was quite fiddly to build. That prompted yet another redesign, resulting in the Mk3.

Downloads

elksd.zip - a collection of Electron games, just unzip and copy to a MicroSD card

Compatibility

See the Mk3 Interface page for details.
